    Insulating Epoxy Powder Coating Machine For Armature Rotor Automotive Motorcycle

    Ask Lasest Price
    Brand Name : nide
    Model Number : ND-JF-80GG
    Certification : CE
    Price : negotiable
    Supply Ability : 120 sets / year
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    Insulating Epoxy Powder Coating Machine For Armature Rotor Automotive Motorcycle

    Mini rotor epoxy powder insulating coating machine for armature rotor automotive motorcycle


    (1) Machine function and characteristic of the armature/rotor powder coating machine

    This automatic armature rotor epoxy powder coating machine has a wide application, and easy for operation. The coated armature has shiny surface, even thickness, good electricity performance.
    Small motor is transported to fluid bed by screw for coating. Insulation power is equally coated on its surface, and then cured by high frequency heating. This machine consists of coating, curing, cooling and powder recycling. Except loading and unloading, the other processes are completed automatically.


    (2) Main technical data of the armature/rotor powder coating machine

    Working piece max O.D:120mm
    Working piece max stack length70mm
    Working piece max shaft length180mm
    Recycle efficiency≥95%
    Production efficiency:1500pcs/hour
    Coating thickness:0.15mm-0.5mm adjustable
    Line speed m/min:0.1-1.5m adjustable
    Screw rod length3500mm
    Feeding speed0~0.5RPM
    Static voltage0~60KN
    Static current≤200μA
    Air source pressure0.5~0.7MPa
    Voltage380V three phase
    High frequency power30KW
    Total dimension4900mm*2500mm*2000
    Weight3000Kgs

    (3) Applications of the armature/rotor powder coating machine

    This rotor powder coating machine is widely used in mini rotor insulating coating, such as automotive, motorcycle, power cycle, toy and small electromotor of appliance.
