    Customized Color Stator Wedge Inserting Machine For Electric Power Steering Motor

    Ask Lasest Price
    Brand Name : Nide
    Model Number : CZGL2-160-190A
    Certification : None
    Price : Negotiable
    Payment Terms : T/T, L/C
    Delivery Time : 35 working days
    • Product Details
    • Company Profile

    Customized Color Stator Wedge Inserting Machine For Electric Power Steering Motor

    Customized Color Stator Wedge Inserting Machine For Electric Power Steering Motor


    Quick Detail:

    1. Model No.:CZGL2-160/190
    2. This machine is used for preparing wedge.
    3.It features as easy operation, fast tooling change.
    4. the machine is suitable for smal quantity with multi sizes stator production.
    (1) Technical parameter:
    Stack height20~160mm
    Stator ID50-120mm
    Stator OD≤190mm
    Efficiency0.45s/s
    Power supply220V/ 50/60Hz 0.75Kw
    Weight250Kg
    Dimension1200*700*1100mm


    (2) Application:
    This machine is used for wedge inserting especially for simple winding inserting machine.

    (3) Machine function and characteristic:
    This machine is used for preparing wedge. It inserts the wedge into jig so that operator could transfer wedge into the depot of semi-auto coil inserting machine, Wedge feeding, edge folding(optional) and forming process are all done automatic by machine. It features as easy operation, fast tooling change, the machine is suitable for small quantity with multi sizes stator production.

    (4)Motor wedge insertion diagram:


    Besides paper inserting machine, we also supply different types of electrical insulation materials for stator or armatures, such as insulation paper and insulation wedge with different class degree. DMD Class B/F, DM Class B/F, Polyester film Class E, Red Vulcanized Fiber Class A, NH& NHN, etc
    electrical insulation meterial motor winding insulation paper
