Middle size stator winding automatic lacing machine for single phase motor

Quick Detail:

1. The stator coil lacing machine is controlled by servo system.

2.PLC and touch screen control the lacer equipment.

Description:

This lacing machine is equipped with pressing, automatic feeding, automatic cutting device. The stator should be loaded vertically into this lacing machine. The overhang windings are simultaneously laced by two twin needles controlled by servo system. The needle indexing, hooking and stator indexing process are controlled by servo system. The spindle adopts frequency speed control. The lacing type, such as slot by slot lacing, interval lacing, and fancy lacing could be programed in the touch screen. This lacing machine is characterized by compact appearance, fast speed, low noise; simple operation and easy tooling change.

Applications:

This stator coil lacing machine is appropriate for micro induction motor like conditioner motor, washer motor, compressor motor, fan motor, alternator motor, pump motor etc.

Machine structure
This machine is consist of machine body, needle, nozzle rotating part, needle fore and back movement,nozzle swing part, needle up and down movement part, stator indexing part,thread feeding,thread cutting part.

Lacing machine technical data

Competitive advantages
Variety of application, easy operation.
We have Overseas Service Center.
Machine is controlled by PLC. All the parameter can be set in the touch screen.
It is suitable for stators with different model number and dimension.
The operation and tooling change process is easy.
We could customize machine for our customer as per their requirement.
We directly supply our machines to many countries, like USA, France, Turkey, Iran, India, Brazil, Argentina, Mexico etc.
This machine is controlled by PLC. All the parameter could be set on the touch screen,

Lacing machine operation method
1. Connect machine to power source and air source. Do threading.
2. Put the stator in the tooling.
3. Switch to "auto" mode. The press "start" button by two hands.
4. Machine will automatically do the lacing.

Machine detail picture
