    Stator Insulation Paper Shaping And Cutting Machine For Two Slots Motor


    Stator Insulation paper shaping and cutting machine for two slots motor


    The electric motor Stator paper forming and cutting machine is suitable for two poles stator insulation paper forming and cutting. During the paper forming and cutting machine running, the whole process will be done by machine automatically. The Stator paper forming and cutting machine is easy to operate and easy to change tooling. If user need the paper with punching hole, this machine can also do it.


    Technical parameter:

    Item

    Specification

    Stator I.D range

    30~55 mm

    Stator slot number

    2 slots

    Max stator O.D range

    50~95mm

    Stack length

    5~80mm

    Paper width

    Less than 130mm

    Paper thickness

    Less than 1mm

    Productivity

    4pcs/second

    Air pressure

    0.4~0.7Mpa

    Machine weight

    110Kgs

    Machine dimension

    490*790*1200mm


    Information needed for paper cutting and forming machine inquiry
    It will be better if customer could send us detailed drawing including below information.
    1. Stator lamination drawing
    2. Stator stack drawing
    3. insulation paper drawing and its material
    4. Stator application
    5. Required productivity
    6. Other technical requirement
    If possible, it will be better if customer can send us samples.


    Competitive advantages

    Variety of application, easy operation.

    We have Overseas Service Center.

    Machine is controlled by PLC. All the parameter can be set in the touch screen.

    It is suitable for stators with different model number and dimension.

    The operation and tooling change process is easy.

    We could customize machine for our customer as per their requirement.

    We directly supply our machines to many countries, like USA, France, Turkey, Iran, India, Brazil, Argentina, Mexico etc.


    This paper forming and cutting machine is suitable for below kind stators


    Besides paper inserting machine, we also supply different types of electrical insulation materials for stator or armatures, such as insulation paper and insulation wedge with different class degree. DMD Class B/F, DM Class B/F, Polyester film Class E, Red Vulcanized Fiber Class A, NH& NHN, etc
