    Hydraulic System Automatic Stator Coil winding Final Forming Machine PLC Control

    Ask Lasest Price
    Brand Name : Nide
    Model Number : Z3XL1-150(160)
    Certification : Main electric components are CE certificated.
    Price : Negotiable
    Payment Terms : T/T, L/C
    Delivery Time : 35 working days
    Supply Ability : 60 sets per month
    • Product Details
    • Company Profile

    Hydraulic System Automatic Stator Coil winding Final Forming Machine PLC Control


    Hydraulic System Automatic Stator Coil Final Forming Machine PLC Control


    Quick Detail:

    1. Model No.:Z3XL1-150/160
    2. The stator coil final forming machine is used for stator coil final forming,
    3. The stator coil final forming machine is driven by the hydraulic system
    4. The stator coil final forming machine is controlled by the PLC.
    5. The stator coil final forming machine is of highly efficiency and qualified forming.


    Technical parameter:

    Stator I.D

    50~100mm

    Stator O.D

    ≤160mm

    Stack height

    16~100mm

    Displacement of cylinder

    20F

    Power supply

    380V/50/60Hz 1.5KW

    Weight

    700Kg

    Dimension

    650*900*2300mm


    Description:

    The Stator Coil Final Forming Machine is used for stator coil final forming, it is driven by the hydraulic system, controlled by the PLC. The forming machine equipment's tooling design adopts flexible principles of inner expansion. The outer wrapping and edge forming form the stator winding. The stator coil final forming machine can ensure appropriate winding outside dimension after lacing..


    Required information for quotation: stator drawing before forming and after forming, including stator O.D, stator I.D, stator stack height, and end coil dimension.

    Competitive advantages:

    It is of highly efficiency and qualified forming. High technology, stable performance and reasonable price.


    Regular maintenance

    Regularly check if there is water in the filter. If yes, discharge the water.

    Regularly check if there is sufficient oil in the atomized lubricator. If not, replenish it.

    Regularly check the lubricating condition of guide mechanism, replenish if necessary.

    Check and clean up the electrical cabinet once every three months.

    Check solenoid valve screws and pipe connectors once every 3 months.

    Check filter once every 2 months.


    Stator forming machine

    stator forming machine


    Stator final forming machine video
