    Customized 7AM Thermal Protector Home Appliance Motor Protectors

    Ask Lasest Price
    Brand Name : NIDE
    Model Number : NDPJ-RBHQ-80
    Price : negotiate
    Payment Terms : negotiate
    Supply Ability : 100000/month
    Delivery Time : negotiate
    • Product Details
    • Company Profile

    Customized 7AM Thermal Protector Home Appliance Motor Protectors

    7AM Thermal Protector Home Appliance Motor Protectors


    7AM Thermal Protector delivers the maximum protection in the smallest package . The bimetal disc welded in a steel can provides excellent thermal sensitivity and maximum protection properties. Each 7AM temperature rating has a bimetal disc specifically manufactured for that rating. Each device is then calibrated and checked for opening temperature. This results in optimum snap–acting open and reset characteristics necessary to achieve consistent performance over the required cycle life.


    7Am Thermal Protector Features

    Positive make and break

    Individually temperature checked

    Compact, miniature size

    Repeatable temperature performance over life

    Gasketed steel case suitable for most impregnation processes

    Current and temperature sensitivity for maximum design flexibility and application

    Wide selection of leads and insulating sleeves


    7Am Thermal Protector Specifications

    Product name:7AM Thermal Protector Motor Protector
    Rated Voltage:125 Vac / 250 Vac
    Dimensions:20.2 x 10.8 x 4.9 mm (including terminals)
    Life:10,000 cycles / 8 A / 250 Vac (see approvals sheets)
    Open Temperature:70°C to 175°C in increments of 5°C
    Temperature Tolerance:±5°C
    Differential Temperature:19°C to 54°C, depending on open temperature
    Seal:

    High-seal and low-seal gasket material available
