Single-phase motor stator automatic coil winding and inserting machine

This stator coil winding and inserting machine is suitable for single-phase motor stator manufacturing. It adopts an integrated automatic design of coil winding and insertion. It can be purchased as a single machine, or can match with a manipulator, combine with other motor stator manufacturing equipment to form a fully automatic stator manufacturing line.

The whole process of stator winding and embedding is automated, just take the stator, save labor and improve work efficiency.

During winding, the coil will be auto wound to the tooling, so as to avoid the wire damage and snap caused by wire cross and disorder during manual wire transfer.

The coil winding and inserting station is controlled by the dual-power servo motor, and the parameters such as winding, pushing the line, pushing the height of the paper, and changing the product stack thickness can be set on the touch screen.

1. Motor Stator Making Machine Application

At present, low-power motors are the most widely used products in the motor system.

Single-phase motors are the most widely used in low-power motors due to their large starting torque and small starting current. Mainly used in agricultural processing machinery, air compressors, mills, fans, ventilators, washing machines, refrigerator compressors, small machine tools, food machinery, medical equipment, blowers, etc.

2. Motor Stator Making Machine Feature

2.1 4-station design with three-head winding and one-head coil inserting. With 4 stations working at the same time, The machine will be save labor cost, high efficiency, and can fulfill the 2-pole, 4-pole and 6-pole three-phase motor coil winding.

2.2 Adopts a full set of servo motor drive to ensure the accuracy and stability of the machine operation. The coil insertion station adopts dual power push line to meet the production of high slot full rate products.

2.3 Simultaneously realize two sets of wires to be wound at the same time, and adds two insulation paper inserting stations, which realizes the function of adding the phase insulation at the same time, and reduces the manual operation of the post process.

2.4.Specially designed for the stator winding of motor, and integrates winding, grooved wedge and ruled line.
