    Customized Electric Motor Spare Parts Composited Insulation Paper 6641 NMN

    Ask Lasest Price
    Brand Name : NIDE
    Model Number : NDPJ-JYZ-6641D
    Certification : CE
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 10000000 kilogram per month
    Delivery Time : 30 working days
    • Product Details
    • Company Profile

    Customized Electric Motor Spare Parts Composited Insulation Paper 6641 NMN

    Electrical Nomex/mylar/nomex paper composited insulation paper 6641 NMN for motor winding


    insulation polymide film inducion:

    NIDE 6641 motor insulaton material is a class C insulation polyimide film with high temperature resistance, radiation resistance and excellent dielectric properties. It is widely used for electrical insulation of special motors, electrical insulation and other applications.


    polymide film specification:

    Testing ItemUnitIndex
    Appearance1.the surface shall be even, smooth, no bubble, no pin hole, no wrinkle or flaw
    2.No damage during de-coil
    3.Doesn't include conductive particle or other impurities
    1.the surface shall be even, smooth, no bubble, no pin hole, no wrinkle or flaw
    2.No damage during de-coil
    3.Doesn't include conductive particle or other impurities
    1.the surface shall be even, smooth, no bubble, no pin hole, no wrinkle or flaw
    2.No damage during de-coil
    3.Doesn't include conductive particle or other impurities
    Thicknessmm0.2±0.030.3±0.030.25±0.03
    Rationg/m2200±30300±45250±37
    Thermal bonding 180±2℃,10minno layering, no bubble, no molten glueno layering, no bubble, no molten glueno layering, no bubble, no molten glue
    Bonding strength at normal temperatureno layeringno layeringno layering
    Tensile strengthLongitudinalNo Bendingn/10mm≥120≥255≥150
    After bending≥105≥245≥130
    HorizontalNo Bendingn/10mm≥105≥245≥130
    After bending≥95≥235≥120
    Elogation rateLongitudinalNo Bending%≥10≥5≥10
    After bending≥10≥5≥10
    HorizontalNo Bending%≥15≥10≥15
    After bending≥15≥10≥15
    Break-down voltage(room temperature)kv≥8≥11.5≥10

    Electrical Nomex/mylar/nomex paper composited insulation paper 6641 NMN for motor winding


    Information needed for insulation material inquiry

    It will be better if customer could send us detailed drawing including below information.

    1. Insulation material type: insulation paper, wedge, (including DMD,DM, polyester film, PMP,PET,Red Vulcanized Fiber)

    2. Insulation material dimension: width, thickness, tolerance.

    3. Insulation material thermal class: Class F, Class E, Class B, Class H

    4. Insulation material applications

    5. Required quantity: normally its weight

    6. Other technical requirement.


    We also supply different types of electrical insulation materials for stator or armatures, such as insulation paper and insulation wedge with different class degree. DMD Class B/F, DM Class B/F, Polyester film Class E, Red Vulcanized Fiber Class A, NH& NHN, etc


    insulation-paper-material-for-motor-winding-manufacturing


    electrical insulation paper material


    About Motor component and accessories


    NIDE can supply the full range of electric motor components such as commutator, ball bearing, thermal protector, carbon brush, insulation paper, shaft, magnet, fan, motor cover,etc.
